BlueLine Implant

DSI Blue Line spiral implants are made especially for Immediate loading in a wide variety of cases of different bone types. It is possible thanks to the great stability of the iconic "aggressive" geometric shape designed using the latest technology. DSI Blue Line spiral implant shape includes dual threads, two spiral channels stemming from the apex, micro-grooves on the implant top, and a changing thread thickness along with the implant. The result is that soft bone is collected and compressed during the implantation. It creates a perfectly uniform high-quality platform ready for immediate loading. Platform switching preserves the crestal bone height and soft tissue levels, increasing the quality of outcomes in the treatments.

Inquire Now

DSI Blue Line spiral implants are indispensable for immediate loading technique and a high level of stability. Could be used with different bone types combining all the latest technologies and developments in the industry.‍ Ideally suited for multi-unit immediate load applications and insertion into fresh extraction sites.

Product Details

All DSI implants undergo the strictest quality control measures. DSI assures that a high percentage of samples are taken from every batch. Each sample passes a very strict set of tests of cleanliness and conformity. Thus providing minimal rejections afterward. All of the products attend to the highest international standards. All DSI Implants implants are made of titanium alloy Ti-6Al-4V ELI, in accordance with ASTM-F136-02

SLA Surface Treatment:

The classic SLA surface, short of «Sand-blast, Large grit, Acid-etch» is based on large aluminum oxide Al2O3 particles sandblasting technique that generates a macro-roughness on the titanium surface. Sandblasting is followed by an acid-etching batch at high temperatures. As a result, subtle-sized 2-5 micron micropores appear at the implant surface. This unique macro/micro-topography provides an ideal structure for cell attachment while reducing the possibility of bacterial colonization. SLA surface treatment is one of the most used in modern dental implantology. The studies confirmed its strong long-term performance, high mechanical stability, and low odds of developing peri-implantitis. DSI has improved the process, making it hands-free and minimizing the aluminum oxide residuals that may remain on the surface and could significantly impair osseointegration.


• Made of titanium alloy Ti-6Al-4V ELI, in accordance with ASTM-F136-02.
• SLA surface treatment for better osseointegration and reduced bacterial migration.
• Connection: 2.42 Internal Hex, Zimmer-SV compatible.
• Increased implant-abutment contact area.
• Aggressive, wide thread pitch, sharp and deep.
• Bone condensing property provides excellent primary stability.
• A special shape increases the implant's external surface, accelerating the healing process.
• Ideally suited for multi-unit immediate load applications and insertion into fresh extraction sites.
• Platform switch design.
• Recommended for soft and mildly dense bones.
• Self-tapping capability.
• Two spiral channels stemming from the apex to adjust the implant integrity.


SBI0835, SBI1035, SBI1135, SBI1335, SBI1635: Ø3.5mm H (8, 10, 11.5, 13 and 16mm)
SBI0638, SBI0838, SBI1038, SBI1138, SBI1338, SBI1638: Ø3.75mm H (6, 8, 10, 11.5, 13 and 16mm)
SBI0642, SBI0842, SBI1042, SBI1142, SBI1342, SBI1642: Ø4.2mm H (6, 8, 10, 11.5, 13 and 16mm)
SBI0650, SBI0850, SBI1050, SBI1150, SBI1350, SBI1650: Ø5.0mm H (6, 8, 10, 11.5, 13 and 16mm)
SBI0660, SBI0860, SBI1060, SBI1160, SBI1360: Ø6.0mm H (6, 8, 10, 11.5, and 13mm)
